MAXPULL® BRAND :- 50 YEARS PROVEN
RATCHET LEVER HOISTS – RDSO APPROVED MANUFACTURING RANGE – UPTO 6TONNES CAPACITY

Salient Design & Constructional Features :

SIMPLE DESIGN- EASY OPERATION-LIGHT WEIGHT AND COMPACT- LOW HEAD ROOM.
Weight	Very light compared to capacity.
Load Brake	The Load Brake is of Screw & Disc type self actuating .The Brake automatically sets & holds the Load at any point .
Hand Wheel	Conviniently shaped to enable quick winding of loose chains when the machine is free from load.
Hooks	Forged Steel Shank Hooks to IS:8610.
Roller Chain	Made of high tensile steel.
Other parts	Gears, Sprocket wheels, ratchet wheel,pawl etc. are made of high tensile steel & heat treated.
Test	The machines are tested to 50% overload.

TECHINICAL SPECIFICATION :-

Rated Capacity (Tonnes)	Std lift (M)	No of Strands of load chain.	Length of Lever
0.8	1.40	1	500
1.60	1.40	1	500
3.20	1.40	2	500
4.50	1.40	3	500
5.00	1.40	3	500
6.00	1.40	4	550

Specifications for other capacities shall be provided on request. Specification given above are approximate & are subject to change without notice since all these products are under constant research for development.
